Specifications: Brand Name: Happymodel Materials: ABS Color: Black Standard JR Bay dimension Weight: 20gram Compatible with Happymodel ES24TX / ES24TX PRO / ES900TX / ES915TX TX module. Reserved cooling fan installation position, support 20x20x6mm fan.
Specifications: Brand Happymodel Size 20mmx20mmx6mm Working voltage DC 5V Working current <80ma @DC5V Speed 1300RPM Plug SH 1.0 2pin
The Happymodel 2.4GHz ELRS nano series receiver is an open source program based on ExpressLRS, we have 3 types rx module released. The PP RX is designed by @Jye Smith from ExpressLRS development team. Its main hardware architecture is STM32L432KBU6 MCU and SX1280 RF chip. It has a built-in ceramic antenna, which is super…
Frequency (MHz) 2400.0 Efficiency (dBi) -0.89 Gain (dBi) 2.23 Efficiency (%) 81.46 Directivity (dB) 5.12 Peak Gain Position (Theta) 180.00 Peak Gain Position (Phi) 330.00 Efficiency ThetaPol (%) 20.90 Efficiency PhiPol (%) 60.56 Upper Hem. Efficiency (%) 39.93 Lower Hem. Efficiency (%) 41.54 Connector IPEX/IPX/U.FL Antenna width 52mm Antenna length 40mm/90mm(optional)
