Noticed: IR1 is the signal of RX1 with inverter ,used for SBUS receiver. RX1 and IR1 couldn’t be used at the same time . CrazybeeX series flight controller is the first 5in1 AIO flight controller which could handle 2s. It’s a better upgrade flight controller for your whoops. We could use this flight controller to…
Noticed: IR1 is the signal of RX1 with inverter ,used for SBUS receiver. RX1 and IR1 couldn’t be used at the same time . CrazybeeX series flight controller is the first 5in1 AIO flight controller which could handle 2s. It’s a better upgrade flight controller for your whoops. We could use this flight controller to…
Notes: R1(RX1) Pad is used for IBUS/DSM2/DSMX signal input IR1(IRX1) Pad is used for SBUS signal input (Already inverted) R1 and IR1 Cannot be used simultaneously Flight controller (Frsky SPI RX version) CRAZYBEE F4 Lite Frsky version Firmware target: CrazybeeF4FR (Flysky SPI RX version) CRAZYBEE F4 Lite Flysky version Firmware target: CrazybeeF4FS MCU:STM32F411CEU6 (100MHZ, 512K…
(Frsky version) CRAZYBEE F4FR PRO V3.0 Firmware target: CrazybeeF4FR (Flysky version) CRAZYBEE F4FS PRO V3.0 Firmware target: CrazybeeF4FS (No RX version) CRAZYBEE F4 PRO V3.0 Firmware target: CrazybeeF4DX MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 2-4S battery input (DC 7-17V) Built-in 10A(each) Blheli_S 4in1 ESC Dshot600 ready Frsky…
