Nov152023

X12 ELRS Pro v1.1 5-IN-1 AIO flight controller built-in 2.4G ELRS V3.0 and OPENVTX

Specifications: Brand Name: Happymodel Item Name: X12 ELRS Pro AIO 5-IN-1 Flight controller built-in 12A ESC and OPENVTX Betaflight firmware target: betaflight_4.4.0_STM32F411 VTX antenna: U.FL Weight: 5.1g Size: 30mm*30mm*8mm Flight controller X12 ELRS Pro v1.1 AIO 5-IN-1 Flight controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) ,ESP32-PICO-D4 Sensor: ICM42688P(SPI connection) Mount hole size: 25.5mm*25.5mm Power supply: 1-2S battery…

Read article

Sep42023

SuperX HD ELRS 1-2S AIO flight controlelr built-in 12A esc and UART elrs receiver for Digital whoop

Flight controllerLeave a comment

Notes: Before buying this flight controller, make sure you have good soldering skills and can solder tiny pads. Any flight controller failure caused by welding errors is not covered by the warranty. Update log：Add ESP8285 boot pads better for upgrade onboard elrs receiver firmware Flight controllerSuperX HD ELRS Betaflight 4.4.2 firmware ready Firmware target: CRAZYBEEF4DX MCU:STM32F411CEU6…

Read article

May262023

CrazyF405HD ELRS 1-2S AIO FC built-in UART ELRS receiver and 12A BLHELI_S ESC

Flight controller1 Comment

Only the v1.0 version of the CrazyF405 flight controller has silk screen printing errors, and the V1.1 and V2.0 versions have been fixed A flight controller with a built-in Serial ELRS receiver and 4-IN-1 Blheli_S 12A ESC specially developed for Digital HD FPV, which removes the analog OSD chip 7456, optimizes the PCB layout,…

Read article

Mar112023

CrossF4 ELRS 1-2S flight controller for Tinywhoop with BMI270 IMU and serial UART ELRS V3.0 receiver

Flight controller1 Comment

Betaflight configuration: ***Bind procedure is the same like Happymodel EP1/EP2 receiver , need to upgrade your ExpressLRS TX module to V3.X version first. ***Thanks to our team pilot “Jiggy” provide the bind instruction Alternative-Binding-Method-for-UART-Based-ELRS-RX Flight controller Firmware target: CRAZYBEEF4DX4.3.2 MCU:STM32F411CEU6 (100MHz, 512K FLASH) Sensor: BMI270(SPI connection) Power supply: 1-2S Lipo Lihv battery input (DC 2.8V~8.7V) Built-in…

Read article
